Kyoritsu 100A AC True RMS Clamp Meter

Name: Kyoritsu 100A AC True RMS Clamp Meter
Brand: FIELDMAN CONTROL SYSTEM
Price: 12500 INR
Availability: InStock

Price 12500 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Kyoritsu 100A AC True RMS Clamp Meter Specification

Humidity
85% RH (no condensation)

Product Type
Clamp Meter

Mounting Type
Handheld

Equipment Type
Clamp Meter

Features
True RMS, Data Hold, Auto Power Off

Resolution
0.01A (Current), 0.1V (Voltage)

Test Range
AC Current: 0.01A to 100A, AC Voltage: Up to 600V

Interface Type
Clamp and Test Leads

Operating Voltage
Battery Powered (3V total)

Response Time
Approx. 2 seconds

Temperature
Operating: 0C to 40C

Accuracy
(1.5% rdg 5dgt) for AC Current

Display Type
Digital LCD

Application
Electrical AC current and voltage measurement

Power Supply
Battery

Automation Grade
Manual

Frequency
50/60Hz

Measuring Range
AC Current: 0.01A~100A, AC Voltage: Up to 600V

Usage
Measuring AC current, voltage, resistance, and continuity

Machine Weight
Approx. 300g (including battery)

Test Width
Jaw Opening: 33mm

Control Mode
Manual Operation

Peak Hold
Yes

Continuity Buzzer
Yes (less than 120)

Clamp Diameter
33mm max conductor size

Resistance Range
0.1 to 40k

Safety Standard
IEC 61010-1, CAT III 600V

Drop Proof
Drop resistant from 1 meter

Low Battery Indication
Yes

Storage Temperature
-10C to 60C

Auto Range
Yes

Kyoritsu 100A AC True RMS Clamp Meter Trade Information

Minimum Order Quantity
1 Piece

Main Export Market(s)
Australia, North America, South America, Eastern Europe, Western Europe, Middle East, Africa, Central America, Asia

Main Domestic Market
All India

Kyoritsu 100A AC True RMS Clamp Meter About

Digital Clamp Meter:

Fully Safety jaw
Ergonomic over-molded body gives convenient one-hand operation
Large easy-to-read display with 0.01A resolution
Accurate reading with True RMS 60/600/1000A auto-ranging
Long battery life

True RMS Precision for Demanding Environments

The Kyoritsu 100A AC True RMS Clamp Meter ensures accurate readings, even on complex waveforms commonly found in industrial settings. Its high resolution and True RMS technology allow precise measurements, making it an indispensable tool for electricians and maintenance professionals.

Robust Safety and Durability Features

Engineered to withstand harsh work conditions, this clamp meter meets IEC 61010-1, CAT III 600V safety standards. With a 1-meter drop-resistant build and a design that works reliably in temperature extremes, the unit is well-suited for industrial site use.

Convenient Measurement Functions and User-Friendly Interface

The clamp meter provides an easy-to-read digital LCD display, auto ranging, data hold, peak hold, and continuity buzzer features. Its 33mm jaw accommodates larger conductors for versatile field use, with auto power-off to extend battery life.

FAQ's of Kyoritsu 100A AC True RMS Clamp Meter:

Q: How does the True RMS feature benefit measurement accuracy in the Kyoritsu 100A Clamp Meter?

A: The True RMS capability provides accurate readings of AC current and voltage, even when measuring non-sinusoidal or distorted waveforms. This ensures that measurements in industrial environments, where loads are often not purely resistive, remain precise.

Q: What is the maximum conductor size the clamp can accommodate, and where is it useful?

A: The clamp can open up to 33mm, suitable for measuring current in various industrial and commercial electrical installations. Its large jaw allows testing on thicker cables often found in such settings.

Q: When should the continuity buzzer function be used?

A: Use the continuity buzzer when checking circuit connections for breaks or faults. The buzzer sounds if the resistance is less than 120, allowing for quick identification of conductive paths and troubleshooting electrical issues.

Q: What is the recommended process for measuring AC current with this clamp meter?

A: To measure AC current, set the meter to the appropriate current range, open the jaws, and clamp them around a single conductor. The current will then be displayed on the LCD. Utilize the data hold or peak hold functions as needed to capture transient readings.

Q: How does the auto range feature enhance usability during testing?

A: The auto range automatically selects the optimal measurement range, reducing manual adjustments. This simplifies operation, minimizes error risk, and speeds up the testing process, especially when measuring varying current or voltage levels.

Q: What environments can the meter be safely operated in?

A: The clamp meter operates effectively between 0C to 40C and up to 85% relative humidity without condensation. Its rugged design and drop resistance make it reliable for use in both indoor and challenging industrial field environments.
